gitlab分离克隆端口笔记

一、需求描述

​ 要求gitlab访问端口跟克隆端口不一致，克隆端口只允许git操作推拉代码，不允许访问页面等其他操作。

二、docker compose部署

• web页面访问端口为20023，也可以克隆代码。20021端口只能克隆代码

1、docker compose部署脚本

services:
  gitlab:
    shm_size: 1G
    container_name: gitlab
    image: gitlab/gitlab-ce:16.3.7-ce.0
    restart: always
    environment:
      GITLAB_OMNIBUS_CONFIG: |
        external_url "http://127.0.0.1:20023"
        # 必须跟external_url保持一致 否则内部跳转会出问题，比如代码仓库里的成员名称跳转403
        nginx['listen_port'] = 20023
        nginx['custom_nginx_config'] = "include /etc/nginx/conf.d/gitlab-clone-only.conf;"
        gitlab_rails['gitlab_shell_ssh_port'] = 20022
        gitlab_rails['gitlab_http_clone_host'] = "127.0.0.1"
        gitlab_rails['gitlab_http_clone_port'] = 20021
      TZ: "Asia/Shanghai"
    ports:
      - "20021:20021"
      - "20022:22"
      - "20023:20023"
    volumes:
      - ./data:/var/opt/gitlab
      - ./logs:/var/log/gitlab
      - ./conf:/etc/gitlab
      - /etc/localtime:/etc/localtime:ro
      - ./gitlab-clone-only.conf:/etc/nginx/conf.d/gitlab-clone-only.conf

2、gitlab 屏蔽20021端口访问nginx配置

# cat gitlab-clone-only.conf
server {
    listen 0.0.0.0:20021;
    #listen *:20021 ssl http2;  # 注意该配置，没有该配置将导致https拉取代码失败
    server_name 127.0.0.1;
    #ssl_certificate /etc/gitlab/ssl/server.crt;
    #ssl_certificate_key /etc/gitlab/ssl/server.key;
    client_max_body_size 1024m;
    location ~ (\.git(/.*)?$) {
        proxy_cache off;
        proxy_pass http://gitlab-workhorse;
        proxy_request_buffering off;
    }
    location / {
        proxy_cache off;
        #proxy_pass http://gitlab-workhorse;
        return 403;
    }
}

三、k8s部署

• web页面访问端口为31080，也可以克隆代码。31088端口只能克隆代码

root@master:/opt/gitlab# cat deployment.yml
# gitlab-nginx-configmap.yml
apiVersion: v1
kind: ConfigMap
metadata:
  name: gitlab-nginx-config
  namespace: middleware
data:
  gitlab-http-clone-only.conf: |
    server {
      listen 0.0.0.0:31088;


      server_name 192.168.41.50;

      location ~ (\.git(/.*)?$) {
        proxy_cache off;
        proxy_pass http://gitlab-workhorse;
        proxy_request_buffering off;
      }


      location / {
        proxy_cache off;
        #proxy_pass  http://gitlab-workhorse;
        return 403;
      }

    }
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: gitlab-ee
  namespace: middleware
spec:
  selector:
    matchLabels:
      app: gitlab
  # 项目的提交历史记录将只保留最近的 100 次提交 超出这个范围的提交将被删除或不可访问（具体取决于 GitLab 的实现方式）
  revisionHistoryLimit: 100
  template:
    metadata:
      labels:
        app: gitlab
    spec:
      containers:
      - env:
        - name: GITLAB_OMNIBUS_CONFIG
          value: |
            # 强化主服务端口绑定 外部访问 URL
            external_url 'http://192.168.41.50:31080'
            # SSH 相关配置
            gitlab_rails['gitlab_shell_ssh_port'] = 31022
            gitlab_rails['gitlab_ssh_host'] = '192.168.41.50'
            gitlab_rails['time_zone'] = 'Asia/Shanghai'
            # 数据库相关配置
            gitlab_rails['db_adapter'] = "postgresql"
            gitlab_rails['db_encoding'] = "utf8"
            gitlab_rails['db_database'] = "gitlab"
            gitlab_rails['db_username'] = "postgres"
            gitlab_rails['db_password'] = "123456"
            gitlab_rails['db_host'] = '192.168.41.50'
            gitlab_rails['db_port'] = 30431
            # 分离 Workhorse
            #gitlab_workhorse['listen_network'] = 'tcp'
            #gitlab_workhorse['listen_addr'] = '0.0.0.0:31080'
            # 必须跟external_url保持一致 否则内部跳转会出问题，比如代码仓库里的成员名称跳转403
            nginx['listen_port'] = 31080
            nginx['custom_nginx_config'] = "include /etc/nginx/conf.d/gitlab-http-clone-only.conf;"
            # 新增配置，允许使用 31088 端口进行 HTTP 方式的代码操作
            gitlab_rails['gitlab_http_clone_host'] = '192.168.41.50'
            gitlab_rails['gitlab_http_clone_port'] = 31088
        - name: TZ
          value: Asia/Shanghai
        - name: GITLAB_TIMEZONE
          value: Beijing
        # 用于加密 CI 密钥变量及数据库中的重要凭证。如果丢失这个密码，将无法使用已经存在的 CI 密钥。
        - name: GITLAB_SECRETS_DB_KEY_BASE
          value: long-and-random-alpha-numeric-string
        # 用于密码重置链接以及其他“标准”身份验证功能。如果丢失这个密码，电子邮件中的密码重置 token 将重置。
        - name: GITLAB_SECRETS_SECRET_KEY_BASE
          value: long-and-random-alpha-numeric-string
        # 用于加密数据库的 2FA 密钥。如果丢失这个密码，所有用户都无法通过 2FA 登录
        - name: GITLAB_SECRETS_OTP_KEY_BASE
          value: long-and-random-alpha-numeric-string
        - name: GITLAB_ROOT_PASSWORD
          #valueFrom:
          #  secretKeyRef:
          #    name: git-user-pass
          #    key: password
          value: 123456
        - name: GITLAB_ROOT_EMAIL
          value: 851448443@qq.com
        - name: GITLAB_HOST
          value: 192.168.41.50
        - name: GITLAB_PORT
          value: "31080"
        - name: GITLAB_SSH_PORT
          value: "31022"
        - name: GITLAB_NOTIFY_ON_BROKEN_BUILDS
          value: "true"
        - name: GITLAB_NOTIFY_PUSHER
          value: "false"
        - name: GITLAB_BACKUP_SCHEDULE
          value: daily
        - name: GITLAB_BACKUP_TIME
          value: 01:00
        name: gitlab
        image: 192.168.41.200/devops/gitlab/gitlab-ee:16.11.10-ee.0
        imagePullPolicy: IfNotPresent
        ports:
        - containerPort: 443
          name: https
        - containerPort: 31080
          name: http
        - containerPort: 31088
          name: http-git
        - containerPort: 22
          name: ssh
        resources:
          requests:
            memory: "2048Mi"
            cpu: 2
          limits:
            memory: "8096Mi"
            cpu: 4
        volumeMounts:
        - name: timezone
          mountPath: /etc/localtime
          readOnly: true
        - name: gitlab
          mountPath: /etc/gitlab
          subPath: gitlab-config                    # 使用 subPath 在宿主机的挂载目录上设置一个子目录，用于存放上面指定目录的数据
        - name: gitlab
          mountPath: /var/log/gitlab
          subPath: gitlab-logs
        - name: gitlab
          mountPath: /var/opt/gitlab
          subPath: gitlab-data
        - name: gitlab-nginx-config
          mountPath: /etc/nginx/conf.d/gitlab-http-clone-only.conf
          subPath: gitlab-http-clone-only.conf
      imagePullSecrets:
      - name: harbor-secret
      volumes:
      - name: timezone
        hostPath:
          path: /etc/localtime
          type: ""
      - name: gitlab
        persistentVolumeClaim:
          claimName: gitlab-pvc    #绑定下面创建的 PVC
      - name: gitlab-nginx-config  # 新增此行，匹配 volumeMounts 中的名称
        configMap:
          name: gitlab-nginx-config  # 关联已定义的 ConfigMap

---
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: gitlab-pvc
  namespace: middleware
spec:
  storageClassName: nfs-sc
  accessModes:
    - ReadWriteMany
  resources:
    requests:
      storage: 10Gi

---
apiVersion: v1
kind: Service
metadata:
  name: gitlab-svc
  namespace: middleware
spec:
  type: NodePort
  ports:
  - port: 443 # pod端口
    nodePort: 31443 # 外部端口
    targetPort: 443 # 容器端口
    name: https
  - port: 31080
    nodePort: 31080
    targetPort: 31080
    name: http
  - port: 31088
    nodePort: 31088
    targetPort: 31088
    name: http-git
  - port: 22
    nodePort: 31022
    targetPort: 22
    name: ssh
  selector:
    app: gitlab
